The New Holland Construction Small Articulated Loader (SAL) line introduces a groundbreaking solution for operators, excelling in smaller tasks with exceptional lifting capability. Offering the perfect blend of commodity and convenience, these machines provide operators with enhanced visibility, spacious cabs, and a range of attachments for seamless multitasking on any surface.
The new small articulated loader (SAL) line from New Holland equips operators with the compact power to get more done. The effective combination of strength, versatility, and light footprint makes the ML50 Telescopic (T) exceptional for smaller tasks on any surface. A force to be reckoned with, the impressive lifting capacity handles loads with ease. Discover the various features that seek to enhance stability and safety in the ML50T.
With a width of 57.5 inches (1460 mm) and overall height of 99.3 inches (2523 mm) mode ML50T is suitable for landscapers focused on clearing sidewalks or fenced-in areas with limited space. Machine length without a bucket comes in at 175.4 inches (4454 mm), length with bucket at 209.1 inches (5310 mm).
The small articulated loader series provides unmatched agility to maneuver in tight spaces. Perfect for various landscaping and light construction jobs, these machines are just the right size for snow and debris removal on sidewalks and in backyards, hauling landscaping materials, removing fallen trees or for working on jobsites with sensitive surfaces. Don't be misled when reading 'small' in all this talk regarding New Holland's small articulated loaders; the compact size still provides powerful lifting capabilities.
STRENGTH AND STABILITY
Jobsites and tasks requiring heavy machinery power delivered through a compact package can turn to New Holland's small articulated loaders. Model ML50T stacks up to 200.8 inches (5100 mm) in height with a bucket, and carries a maximum dumping height of 133.9 inches (3400 mm) and an ultimate lifting height of 177.2 inches (2044 mm).
The 74 HP (kW) machine is joined by 195.4 lb•ft (265.0 N•m) of peak torque @1,500 RPM, yet still has minimal ground disturbance when turning or hauling on soft ground like turf. The ML50T comes fitted with an open cab, ROPS/FOPS safety roof and a stability-supporting 80.5 inch (2044 mm) wheelbase. The low center of gravity allows for stable operations, contributing to seamless and precise performance.
A RANGE OF POSSIBILITY
The extended lift on the ML50T allows operators to load and unload materials from large trucks, while the extended reach provides more flexibility in dumping, leveling and grading tasks. The telescopic arm provides 171.3 inches (4350 mm) of lift height and tipping load paths from 2,780 lbs (1260 kg) up to 6,170 lbs (2800 kg), depending on loader position. The 11,464 lbs (5200 kg) of operating weight easily knocks out light construction scenarios such as moving pallets or light debris.
WHEN COMPACT MEETS CONVENIENT
STRENGTH AND STABILITY
A RANGE OF POSSIBILITY
