Fransgard LOGGING WINCHES
The Fransgard winch was designed and manufactured in Denmark for over 30 years. Its robust design, and extra weight, will provide great traction and enable skidding logs, even in narrow trails. The heavy-duty butt plate and tow bar, can be sued for dozing the logs, and levelling trails. All winches have a cam-activated clutch system
* All winches include PTO, cable & protective safety screen
* Specially designed cable resists friction for longer wearing life
* 1 year limited warranty on manufacturing defects.
* Owners manual and parts book provided with every winch
* All winches have a cam-activated clutch system
* PTO hookup ground clearance specifications enable choosing the ideal model for your tractor
* Top pulley is mounted on bearings, and extra supports provides additional resistance for heavy loads
* Cable drum tension bracket prevents cable from unspooling
* Replaceable, serrated tow bar strip on V4021 and up
* Replaceable cable drum frame
| Model | Pull Cap | Weight | Tractor Hp Req’d | Cable Length | Cable DIA |
LIST PRICE |
| V3021 | 6600 lbs | 385 lbs. | 25 | 133’ | 5/16" | $5899 |
| V3521 | 7700 lbs | 408 lbs. | 25 | 133’ | 5/16" | $5999 |
| V4021 | 8800 lbs | 657 lbs. | 40 | 167’ | 3/8" | $7599 |
| V5021 | 11,000 lbs | 687 lbs. | 40 | 167’ | 3/8" | $7499 |
| V6521 | 14,300 lbs | 972 lbs. | 80 | 167’ | 7/16" | $10,999 |
|
CAUTION: Timber winches are mounted very close to the tractor for maximum stability, therefore PTO length is critical. Stock length shaft supplied may require shortening to suit tractor. Operator should ensure that the PTO is never operated at over a 30 degree angle. Three point hitch linkage must have lower setting adjusted so winch does not dig into soft ground pulling the or breaking the PTO shaft. There is no warranty on PTO shafts and knuckles broken or bent under the circumstances listed above. Never transport logs hooked to top of winch by cable, always use chains hooked to transport bar which gives a lower center of gravity. NOTE : Please review owners manual as there are specific operating and maintenance instructions - cables are considered a wearing part and are not covered by warranty | ||||||
